Reception walls, salons, med spas, boutiques, offices, restaurants, studios, retail interiors, and premium branded environments.
Back-lit Acrylic Signs
Layered acrylic plaques with soft rear illumination.
Back-lit Acrylic Signs combine a precision-cut clear or frosted acrylic plaque with engraved, printed, vinyl, or applied dimensional branding. Rear-mounted or recessed LEDs wash light across the acrylic and wall while decorative advertising screws or standoffs create a clean architectural offset. Plug-and-play power is standard for many interior projects, with concealed hardwiring available by project.
Plaque
Clear, frosted, or finished acrylic
Power
Plug-in standard; hardwire optional
Mounting
Advertising screws / standoffs
Production Focus
Designed for clean acrylic edges, controlled rear glow, hidden wiring, accurate graphic alignment, and straightforward wall installation.
Built for
project partners
Signage Companies
Design Firms
Franchise Owners
Corporate Accounts
Acrylic carries and reflects the rear illumination while the graphic remains crisp on the face, creating a floating plaque with a soft halo and polished daytime appearance.
Plaque shape, acrylic thickness, graphic method, LED color, brightness control, standoff depth, power connection, cord concealment, wall condition, and installation access.
Technical Specifications
Fabrication data for Back-lit Acrylic Signs.
Review acrylic construction, graphics, rear illumination, power options, standoff mounting, and quote requirements.
Final specificationConfirmed after artwork and wall review
StyleIlluminated acrylic plaque
AcrylicClear, frosted, or custom
PowerPlug-in or hardwired
MountingAdvertising screws / standoffs
ApplicationPrimarily interior
01 / Construction
Construction
Acrylic, graphics, rear LEDs, standoffs, wiring, and the wall surface are designed as one illuminated plaque system.
Acrylic PlaqueClear, frosted, colored, or custom finished
The plaque can be rectangular, contour cut, layered, printed, engraved, or combined with applied dimensional graphics.
Graphic SystemUV print, vinyl, engraving, or applied letters
Graphic method is selected around detail, opacity, color accuracy, illumination, and the desired daytime appearance.
Rear IlluminationEngraved, recessed, or rear-mounted LEDs
LED placement and diffusion are engineered to create a controlled edge glow, rear wash, or halo on the wall.
Standoff AssemblyAdvertising screws / decorative standoffs
Barrel depth, cap style, threaded hardware, anchor layout, and wire clearance establish the wall offset.
02 / Core
Core Specs
Final construction depends on plaque size, acrylic thickness, graphic method, lighting effect, mounting, power, and environment.
Specification
Planning Standard
Production Notes
Plaque Material
Sign-grade acrylic
Clear, frosted, pigmented, mirrored, or printed acrylic may be used depending on the approved design.
Typical Thickness
Approximately 6 mm; project-specific
Larger plaques or special mounting conditions may require thicker material, layering, or added support.
Illumination
Low-voltage LED backlighting
LED color, density, routing, diffusion, and wall reflectivity determine the final glow.
Power Connection
Plug-and-play standard; hardwire optional
A compatible low-voltage power supply can connect to a receptacle, or wiring can be concealed by an electrician.
Mounting
Advertising screws / standoffs
Hole layout, spacer depth, wall anchors, wiring pass-through, and installation template are coordinated.
Application
Primarily interior
Exterior use requires an approved weather-rated plaque, LEDs, wiring, power supply, hardware, and sealing strategy.
03 / Size
Size & Geometry
Plaque proportions, acrylic rigidity, graphic clearance, LED routing, standoff locations, and shipping limits are reviewed together.
Custom ShapeRectangular or contour cut
Outer shape follows approved artwork while maintaining adequate edge clearance and structural strength.
Acrylic ThicknessSelected around size and rigidity
Thickness affects flatness, edge appearance, drilling, weight, illumination, and handling.
Graphic ClearanceSpacing from edges and hardware
Logos, lettering, holes, LED channels, and wire exits must remain coordinated.
Standoff DepthSets wall offset and halo spread
Deeper offsets produce a broader wall wash but increase projection and visible hardware.
Panel JointsLarge plaques may be sectional
Seams, alignment, separate circuits, packaging, and field assembly are planned before fabrication.
Wall ReflectivitySurface color changes the glow
Dark, textured, glossy, or uneven walls can change halo intensity and visual uniformity.
04 / Lighting
Lighting & Electrical
Plug-in and hardwired options are coordinated around power access, wire concealment, controls, and service.
Power OptionsPlug-and-play or concealed hardwire
A low-voltage power supply is matched to the plaque and located where it remains accessible. Plug-in systems are straightforward for interior projects; hardwired concealment requires field electrical work.
Plug-and-PlayPower supply and wall-outlet cord
Suitable when a visible or managed cord is acceptable and a nearby receptacle is available.
HardwiredConcealed permanent connection
Used when the cord and power equipment must be hidden within or behind the wall.
Remote ControlOn/off and brightness available
Compatible static systems may include a handheld remote dimmer and receiver.
Wire ExitRear or edge exit by project
Position is coordinated with the artwork, standoffs, wall penetration, and power location.
Power SupplyLoad-matched and accessible
Capacity, ventilation, enclosure, cord length, and replacement access are confirmed.
Installation TemplateFull-size hole and wire layout
The template supports accurate drilling, plaque alignment, and hardware placement.
05 / Materials
Materials & Mounting
Acrylic, graphics, LEDs, standoffs, anchors, and finishes are selected around appearance and installation.
Clear AcrylicMinimal support appearance
Allows the wall to remain visible and can carry printed, engraved, vinyl, or dimensional graphics.
Frosted AcrylicSofter diffusion and privacy
Creates a more substantial plaque appearance and can soften visible LED or wall details.
Printed / Colored AcrylicCustom daytime branding
UV printing, vinyl, paint, tint, or layered acrylic can match brand colors and opacity requirements.
Applied GraphicsMetal, acrylic, or vinyl elements
Flat-cut logos and letters can add depth and premium material contrast.
Advertising ScrewsDecorative barrel-and-cap hardware
Hardware finish, diameter, depth, anchor type, and hole size are matched to the plaque and wall.
Wall AnchorsSubstrate-specific
Concrete, masonry, wood, metal, or framed walls require compatible anchors and adequate backing.
06 / Quote
Quote Prep
Send the artwork, target size, installation details, and desired lighting or finish so the final construction can be engineered accurately.
Best Starting Point
Send the vector artwork.
Artwork and site information let us confirm geometry, construction, electrical requirements, mounting, pricing, freight, and lead time.
Start a QuoteArtworkAI, EPS, SVG, or vector PDF
Provide the logo, text, desired plaque shape, and graphic layers.
SizeOverall width and height
Provide wall area, viewing distance, and available mounting space.
AcrylicClear, frosted, colored, or custom
Share reference images and the desired daytime transparency or opacity.
LightingColor, brightness, and controls
Confirm white CCT, static color, dimming, remote control, or special effects.
PowerPlug-in or hardwired
Provide receptacle or circuit location and cord-concealment expectations.
WallMaterial and site photos
Wall color, texture, backing, and access affect mounting and halo appearance.
